NORMAL COPYING
5-7
5
Copying from the document glass
When copying originals which cannot be fed from the reversing single pass feeder such as thick originals, open the
document cover and copy the originals from the document glass.
■
■■
■ 1-sided copies of 1-sided originals
1
Set an original on the document glass.
(pages 4-6 to 4-9)
[ How to place the original ]
Place the original in the appropriate position shown
below according to its size. ( Center the original on
the centering scale.)
2
Ensure that the 1-sided to 1-sided copy
mode is selected.
The one-sided to one-
sided mode is selected
when no icon for a two-
sided mode appears in
the dashed area on the
display.
3
Ensure that paper of the same size as the
original is automatically selected. (*Note)
The selected tray will be
highlighted or the
message "LOAD xxxxxx
PAPER." will appear. If
the message appears,
load paper in a paper
tray with paper of the
required size. Even if the
message above is displayed, copying can be
performed onto the currently selected paper.
(*Note) The following requirements must be
satisfied.
Originals of a standard size (11" x 17", 8-1/2" x
14", 8-1/2" x 11", 8-1/2" x 11"R or 5-1/2" x 8-1/2"
(A3, B4, A4, A4R, B5, B5R or A5)) are set and the
auto paper select function is enabled.
If originals of a size other
than the sizes above are
to be copied, manually
select the desired paper
size by touching the
[PAPER SELECT] key
and then touching the
desired paper size
selection key.
The selected key will be highlighted and the paper
selection screen will close. To close the paper
selection screen without making a selection, touch
the [PAPER SELECT] key.
NOTE
Certain restrictions exist depending on the amount of memory installed and the copy settings. (See "Copy mode
output restrictions" and "Guidelines for the number of scannable originals during sort copying" on page 5-4.)
Original Copy
NOTE
Do not place any objects
under the original size
detector, because they
may damage it or the
original size may not be
detected properly.
Original size detector
R
R
8½x14
or B4
11x17 or A3
8½x11 or A4
8½x11
or A4
5½x8½
or A5
Original scale
Centering scale
Original scale
Centering scale
11x17
PLAIN
5½x8½
8½x11
8½x11
DUPLEX
8½x11
ORIGINAL
PAPER SELECT
AUTO 8½x11
100
%
PLAIN
PLAIN
11x17
RECYCLED
8½x14
8½x11
