INSTALLING THE PRINTER DRIVER AND UTILITIES (SOFTWARE INSTALLATION)
14
Installation method 4
Use this procedure to install the software in the following environments:
1. The printer is connected by parallel cable.
2. Windows version: Windows 95/98/Me/NT 4.0*
1
/2000*
1
Installing the software in Windows 95/98/Me or Windows NT 4.0/2000 (Parallel interface)
Install the software as follows.
Before starting the installation, make sure the parallel interface cable is not connected to the machine.
The procedure for installing the printer driver is explained here using Windows Me as an example.
1
Insert the "Software CD-ROM" that
accompanied the machine into your CD-
ROM drive.
2
Double-click [My Computer], and then
double-click the CD-ROM icon.
3
Double-click the [SETUP] icon.
4
The License Agreement window will
appear. Make sure that you understand
the contents of the license agreement, and
then click the [Yes] button.
5
After confirming the message in the
"Welcome" window, click the [Next]
button.
6
Click the [Printer Driver] button.
To view detailed information on the software, click
the [Display Readme] button.
7
Click the [Next] button.
8
Click the [Custom installation] button.
9
Click the [Connected to this computer]
and click the [Next] button.
10
When you are asked to select the
interface, select [Parallel] and click the
[Next] button.
11
Select the printer port and click the [Next]
button.
Select [LPT1] for the printer port.
NOTE
*1 To install the software using the installer, you must have administrator's rights.
