STATUS

INDICATORS

The copier will stop when a misfeed occurs. The misfeed

( ) indicator will blink, and blinking red misfeed location

indicators will indicate the approximate misfeed location.

If paper is accidentally torn during removal, be sure to

remove all pieces.

Be careful not to damage the photoconductive drum.

For misfeeds in optional equipment, see their respective

sections of the operation manual.

First confirm the misfeed location.

MISFEED REMOVAL

Misfeed removal

Misfeed in the bypass tray

Gently pull the misfed paper out.

Lift slightly on the side cover and slide the cover out

until it stops. Close the side cover by pressing the

handle on the cover.

●

The misfeed ( ) indicator will go out.

Misfeed in the copier

Open the bypass tray. Lift slightly on the side cover and

slide the cover out until it stops.

( P.63)

( P.32, 35)

( P.36)

( P.73)
