STATUS

INDICATORS

Open the bypass tray. Lift slightly on the side cover

and slide the cover out until it stops.

Push gently on both sides of the front cover to open the

cover.

Lift the TD cartridge lock release lever and pull the

cartridge out until the green strap handle can be grasped

by the right hand. Lift the cartridge by the handle while

supporting it with the left hand at the green label position

to remove it.

●

For disposal of the old TD cartridge, contact your dealer.

Remove the new TD cartridge from the bag. Hold the

cartridge on both sides and shake it horizontally four or

five times.

TD CARTRIDGE REPLACEMENT

If the machine detects an insufficient amount of toner available, it will stop

copying but will continue to run while feeding toner. During this time the TD

cartridge replacement required ( ) indicator will blink and the START key

indicator will go out. When sufficient toner has been added, the blinking

indicator will go out and the START key indicator will light up indicating

that copying can be resumed. However, if toner addition continued for a

maximum of two minutes, the TD cartridge replacement required indicator

will light up steadily in addition to the START key indicator lighting. This

indicates that the toner supply is low and that a new TD cartridge will be

needed soon. If copying is continued in this state, the copies will gradually

become lighter until the copier stops and the TD cartridge replacement

required ( ) indicator begins to blink, indicating that the cartridge must be

replaced before copying can be resumed. Replace the TD cartridge by

following the procedure below.

For best copying results, be sure to use only

SHARP products.

The package of SHARP toner has the Genuine

Supplies label.

TD cartridge replacement

TD cartridge lock

release lever

4 or 5 times

GENUINE SUPPLIES
