55
Useful Features
Stretch Playback
Available mode:
Tape Playback
Stretch playback allows you to playback a
squeezed image with the wide screen feel
of a movie shown in a theater. Useful when
you want to play back images recorded by
a camera other than this camcorder in wide
mode on a 4:3 TV.
1 In Tape Playback mode, press the
DISPLAY/MODE SET button until the
mode screen appears.
2 Press l or m on the Operation
button to select “STRETCH PB”, then
press the centre of the Operation
button.
• Playback will stop after turning on
stretch playback.
3 Press m to begin stretch playback.
• The picture displays with black
bands.
To cancel stretch playback
Press the centre of the Operation button
in step 3 above.
Notes:
• “Squeeze” is an image compression
technology. A 16:9 image is compressed and
recorded (squeeze recorded) as a 4:3 image.
• In stretch playback mode, you cannot
perform frame advance, slow, and picture
effect playback or copy an image from tape
to card.
• When outputting the stretch playback image
from the DV terminal, the original image
signal will be output.
• When performing stretch playback, the
normal recorded image (picture aspect ratio
4:3) will be stretched as shown below.
4:3 picture aspect
ratio image
Squeezed image
(4:3)
Stretch playback
(16:9)
Stretch playback
EXECUTE
AUD I O DUB
STRETCH PB
PI C. EFFECT
AUDIO
S T R ETCH
P B
STRETCH
PB
21
+
FFREWSTOPPAUSE
C A N C E LCANCE L
VL-Z500S-GB-049-055 04.2.9, 3:22 PM55
