62
Other viewing options
Learning remote control function
You can operate the connected AV products (AV Receiver, Cable Box, SAT tuner, DTV, VCR, DVD, LD) using the
learning function for your remote control unit. This remote control unit has the function that can memorize each
remote control code.
Presetting manufacture codes
1 Slide the Mode switch to match the device to which
you want to preset the remote control signal.
2 Press EDIT/LEARN and 1 at the same time.
• LED flashes continuously.
3 Press 0 – 9 to enter the manufacture code. (See
page 63.)
• Preset mode is finished once the LED no longer lights
up.
A
• To stop the EDIT mode in the middle, press EDIT/LEARN
once more.
• If Mode switch is switched while in EDIT mode, EDIT mode
will be canceled.
• If there is no operation for over 1 minute running, exit this
mode.
• When you enter a code that is not listed, LED flashes
quickly.
• If the table on page 63 does not include your desired
manufacturer or the remote control does not work, you
can make the memory learn its signal by the learn mode.
• The initial mode is “00” (SHARP).
Learning the remote control
1 Be sure to slide the Mode switch to match the
device whose remote control signal you want to be
learned.
2 Press EDIT/LEARN and 2 at the same time.
• LED flashes continuously.
3 Press a button for you want to learn.
• Refer to the assigning buttons to functions on each
page.(See page 64 to 69.)
• The LED changes from lit up to flashing state.
• When the learn mode is finished, LED lights up once
and returns to the learn mode (LED flashes
continuously).
4 To exit learn mode, press EDIT/LEARN.
A
• To stop the EDIT mode in the middle, press EDIT/LEARN
once more.
• If Mode switch is switched while in EDIT mode, EDIT mode
will be canceled.
• If there is no operation for over 1 minute running, exit this
mode.
• If TV POWER is pressed over 2 seconds running (LED
flashes continuously, step 2 above), the learning codes
of the current Mode switch position clear, changing back
to preset manufacturer codes. In this case, the LED turns
off after 2 seconds exiting learning mode.
TV
ANT-A/B
INPUT
SURROUND
FRONT
TWIN
MODE
AV
POWER
MTS CC
SELECT
SUB TWIN CH
ⴐ
ⴑ
FREEZE
MODE
VOL CH
RETURN
MUTE
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN
MENU
POWER
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ
VOL
ⴐ
INFO
VIEW
SLEEP LEARN
EDIT/
ENT
FLASHBACK
DISPLAY
INPUT
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
100
0
RECEIVER
POWER
LEARN
123
456
789
0
TV
ANT-A/B
INPUT
SURROUND
FRONT
TWIN
MODE
AV
POWER
MTS CC
SELECT
SUB TWIN CH
ⴐ
ⴑ
FREEZE
MODE
VOL CH
MUTE
MENU TV/SAT/DVD
FAVORITE CH
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN
MENU
POWER
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ
VOL
ⴐ
INFO
VIEW
SLEEP
EDIT/
ENT
FLASHBACK
DISPLAY
INPUT
TV VCRCBL
/SAT
/DTV
DVD
/LD
100
0.8 to 2.0 inch (2 to 5 cm)
Remote control
(Supplied accessory)
Remote control of
AV product
