PN-E471PN-E421LCD MONITOROPERATION GUIDE

E10Menu item detailsThe menu will differ depending on the input mode.nSCREENAUTO (PC D-SUB/PC RGB)The CLOCK, PHASE, H-POS, and V-POS are automatically

E11nAUDIOTREBLEAdjusts the volume of treble-level sound.BASSAdjusts the volume of bass-level sound.BALANCEAdjusts the balance of the audio sound betwe

E12Menu ItemsAUTO INPUT CHANGESpecify whether to change inputs automatically. When ON is selected and no signal is present in the selected input mode,

E13Menu ItemsnPIP/PbyPPIP MODESSets the display method.OFF ...Displays one screen.PIP ...Displays a sub screen inside a main screen.PbyP

E14Menu ItemsnEnlarge• You can align several monitors and integrate them into a single large screen to display.• Up to ve monitors can be aligned i

E15nSCHEDULEYou can set the time to switch the monitor on and off.Set this function with “SCHEDULE” in the OPTION menu. (See page 12.)SCHEDULE No. PO

E16nADVANCED items (AV input) (See page 10 for additional Menu item details.)FLESH TONEAdjust the hue control.3D-NRReduce the noise of playback images

17EYou can return the settings to their factory-preset values and restrict operations.1. After pressing for about 5 seconds, press , , , and

18EControlling the Monitor with a PC (RS-232C)You can control this monitor from a PC via RS-232C (COM port) on the PC.You can also connect multiple mo

E19Controlling the Monitor with a PC (RS-232C)nResponse code formatWhen a command has been executed correctlyO K Return code(0DH, 0AH)A response is r

2EThis guide contains instructions regarding operation, settings, and similar details.For instructions regarding connection and installation, refer to

E20Controlling the Monitor with a PC (RS-232C)nCommands for ID controlThe command examples shown on this page assume the following connection and ID n

E21Controlling the Monitor with a PC (RS-232C)nRepeater controlThis system has a function to allow setting of multiple monitors connected in a daisy c

E22RS-232C command tableHow to read the command tableCommand: Command eld (See page 18.)Direction: W When the “Parameter” is set in the parameter

E23PICTURE menuFunctionCommand DirectionParameter Reply Control/Response contents *1*2(A) (B)AUTO AGIN W 1 When the input mode is PC D-SUB, PC RGB. -○

E24SETUP menuFunctionCommand DirectionParameter Reply Control/Response contents *1*2(A) (B)OSD H-POSITION OSDH WR 0-100 0-100○○ ○OSD V-POSITION OSDV

E25OPTION menuFunctionCommand DirectionParameter Reply Control/Response contents *1*2(A) (B)DATE/TIME SETTING DATE WRAABBCCDDEE AABBCCDDEEAA: Year, BB

E26Controlling the Monitor with a PC (RS-232C)ENLARGE menu (When the input mode is PC)FunctionCommand DirectionParameter Reply Control/Response conten

E27PIP/PbyP menuFunctionCommand DirectionParameter Reply Control/Response contents *1*2(A) (B)PIP MODES MWIN WR 0-3 0-3 0: OFF, 1: PIP, 2: PbyP, 3: Pb

E28OthersFunctionCommand DirectionParameter Reply Control/Response contents *1*2(A) (B)SCREEN SIZE (PC) WIDE WR 1-5 1-5 1: WIDE, 2: NORMAL, 3: Dot by

29EWhen the PN-ZB01 (optional) is attached, your monitor can be connected to a LAN allowing you to control it from a PC on the LAN. You can also cong

3EnFront view2 34511. LCD panel2. Remote control sensor3. Input switch (See page 5.)4. Power switch5. Power LEDTIPS• Use a pointed object such as a p

30E30 TosetfromaPCWhen the monitor is connected to a PC, LAN settings can be congured via PC. Set up process(1) Connect your monitor to a PC(2)

31E315. Click on “LAN SETUP” under NETWORK. 6. Specify the “DHCP CLIENT”, “IP ADDRESS”,etc. DHCP CLIENTIf your LAN has a DHCP server and you wish to

32E32 INFORMATIONInformation about this monitor appears. CONTROLYou can control the operations corresponding to the buttons ( ) on the remote co

33E33 NETWORK(LANSETUP)This screen allows you to set the settings necessary when the monitor is connected to a LAN.DHCP CLIENTIf your LAN has a DHC

34E34 NETWORK(GENERAL)This screen allows you to specify the general LAN settings.MONITOR NAMESpecify a name for this monitor as it should appear on

35E35 MAIL(RECIPIENT)This screen allows you to specify the recipients of the e-mail sent periodically or when the monitor has an error.RECIPIENT E-

36E36Controlling the Monitor with a PC (LAN) SNMPYou can congure settings related to SNMP.SNMP SETTINGSet whether to enable or disable SNMP.VERSIONS

37ETroubleshootingIf you are experiencing any problem with your display, before calling for service, please review the following troubleshooting tips.

38ESpecicationsnProductSpecicationsModel PN-E471 PN-E421LCD component47" Class [46-15/16 inch (119.3cm) diagonal] TFT LCD42" Class [42-1/

39ESpecicationsnDimensional DrawingsNote that the values shown are approximate values.[PN-E471]42-5/8 [1083]Opening width (41-1/16 [1043])38-1/16 [96

E4Part NamesnRemote control unit123456987 1. Signal transmitter 2. POWER button 3. DISPLAY button (See page 5.) 4. MUTE button (See page 5.)

40ESpecicationsnPower managementThis monitor conforms to VESA DPMS and DVI DMPM. Both your video card and computer must support the same standard in

41EnCompatible signal timing (PC)VESAWideUS TEXTSunScreen resolution Hsync VsyncDot frequencyDigital640 × 480800 × 600848 × 4801024 × 7681152 × 86412

42ESpecicationsnPC/AV DVI-D input terminal pins(DVI-D 24 pin)No. Function No. Function1 TMDS data 2- 13 N.C.2 TMDS data 2+ 14 +5V3 TMDS data 2/4 shie

PN-E471E421 G EN10B(2)

5EBasic Operation123456781. INPUT (Input mode selection)The menu is displayed. Press or to select the input mode, and press to enter.* You can se

E6Basic OperationnSwitching the screen sizeEven when the screen size is changed, the display may remain the same depending on the input signal.WIDE PC

7EMenu ItemsDisplaying the menu screenVideo and audio adjustment and settings of various functions are enabled. This section describes how to use the

E8Menu ItemsList of menu itemsThe displayed menu items vary depending on whether or not the PN-ZB01 (optional) is attached.○: Item is available, -: It

E9Menu ItemPN-ZB01 (optional)Not attached AttachedOPTION DATE/TIME SETTING ○ ○SCHEDULE ○ ○INPUT SELECT DVI - ○BNC - ○HDMI ○ ○AUDIO SELECT PC DVI-D - ○
