Sharp AR-C265P User’s Guide
111
Maintenance Menu
Note: Factory default settings are shown in bold.
Item Settings Explanation
MENU RESET [EXECUTE] Resets menus to the default settings.
SAVE MENU [EXECUTE] Saves current menu settings as default
values. At confirmation prompt, press
ENTER to confirm save, or CANCEL.
POWER SAVE ENABLE
DISABLE
Change this setting to Disable if you do
not want the printer to enter the power
save mode after the specified time.
PAPER BLACK
SETTING
–2 to +2 in
increments of 1
Default = 0
Used for small adjustment when you
experiencse faded print or light specks /
streaking in monochrome printing on
white paper. Select a higher value to
reduce fading, or a lower value to reduce
specks or streaking in high density print
areas.
PAPER COLOR
SETTING
–2 to +2 in
increments of 1
Default = 0
As above, but for color printing.
TRANSPR
BLACK
SETTING
–2 to +2 in
increments of 1
Default = 0
As above, but for mono printing on
transparencies.
TRANSPR
COLOR
SETTING
–2 to +2 in
increments of 1
Default = 0
As above, but for color printing on
transparencies.
