Take the imaging film cartridge out of the print compartment and

place it on a sheet of paper.

Wipe the print head and roller with denatured alcohol.

Print head

Roller

Caution!

•• Do not use benzene or thinner. Avoid touching the print head with hard

objects.

•• The print head may be hot if your fax machine has just received a large

number of documents. If this is the case, allow the print head to cool prior to

cleaning.

Maintenance

126
