Using an LDAP Server: Searching for Destinations and User Authorization
115
3. Network
Scanner
6 Press or until the desired name is selected in the display.
• To check the e-mail address and/or fax number that is listed for a name,
press after selecting the name. (Press to return when finished.)
7 When you have selected the desired name, press .
• If both an e-mail address and a fax number are listed for the selected name,
go to Step 8 below.
• If only an e-mail address or only a fax number is listed, go to Step 9.
8 If both an e-mail address and a fax
number are listed for the selected
name, the screen at right will appear.
Press or to select the
destination type and press .
START/
ENTER
START/
ENTER
SELECT DESTINATION TYPE
1 = E-MAIL
2 = FAX
GLOBAL ADDRESS SEARCH
[Jo
+ Smith]
MORE THAN 16 MATCHES
FOUND.
CONTINUE SELECTING ▼ AGAIN
TO VIEW NEXT 16 MATCHES.
If there are more than 16 matches
for your keyword, the message at
right will appear after you scroll
through the first 16 matches.
Press to continue viewing
the remaining matches.
