SPECIFICATIONS

Machine specifications / copier specifications (Continued)

*1 Output tray (Centre tray) cannot be used when the finisher or saddle stitch finisher is installed.

*2 Type A connectors are located on the front of the machine and on the right side of the machine at the back (total of two

connectors).

Do not use the connectors simultaneously.

When a keyboard is not connected (MX-KBX2), only one connector can be used; simultaneous use is not possible. If you need to

change the connector that is used, contact your service technician.

To receive power supplied from a type A connector, the total current consumption of the connected device should not exceed

500 mA.

Bypass tray

Paper sizes: A3W, A3, B4, A4, A4R, B5, B5R, A5R, envelopes, 12" x 18", 11" x 17", 8-1/2" x 14",

8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,

7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, 8K, 16K, 16KR (Includes automatic paper size

detection function. Entry of paper sizes up to 297 mm x 432 mm (11-5/8" x 17") is

possible.)

Paper weights:

Thin paper (56 g/m

to 59 g/m

(15 lbs. to 16 lbs.)), plain paper (60 g/m

to 105 g/m

(16 lbs. to

28 lbs.)), heavy paper (106 g/m

to 209 g/m

(28 lbs. bond to 110 lbs. index)),

envelopes (75 g/m

to 90 g/m

(20 lbs. to 24 lbs.))

Paper capacity: Standard paper 100 sheets

Paper types:

SHARP-recommended plain paper, recycled paper, coloured paper, heavy paper, thin paper,

transparency film, labels, tab paper, envelopes (Monarch, Com-10, DL, C5)

Duplex module

Paper sizes: A3, B4, A4, A4R, B5, B5R, A5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5",

8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"R, 8K, 16K, 16KR

Paper weight: Plain paper (60 g/m

to 105 g/m

(16 lbs. to 28 lbs.)), heavy paper (106 g/m

209 g/m

(28 lbs. bond to 110 lbs. index))

Paper types: SHARP-recommended plain paper, recycled paper, coloured paper, and heavy paper

Output tray (Centre tray)*

Output method: Face-down output (A3W and 12" x 18" paper can be output to right tray, finisher, or

saddle stitch finisher)

Output capacity: 400 sheets (using SHARP-recommended A4 or 8-1/2" x 11" paper)

(The maximum number of sheets that can be held varies depending on ambient conditions in the

installation location, the type of paper, and the storage conditions of the paper.)

Tray full sensor: Yes

Interface port

LAN connectivity: 10Base-T / 100Base-TX / 1000Base-T

USB connectivity:

Type A connector supports USB 2.0*

Compatibility requirements of USB memory

Memory capacity : Max. 32 GB

Disk Format : FAT32 only

Type B connector supports USB 2.0 (Hi speed)

Required power supply

Local voltage ±10% (For the power supply requirements, see the name plate in the lower corner of

the left side of the machine.)

Power consumption

1.84 kW (220-240 V) / 1.44 kW (100-127 V)

Dimensions

645 mm (W) x 695 mm (D) x 953 mm (H) (25-25/64" (W) x 27-3/8" (D) x 37-33/64" (H)) (With the

reversing single pass feeder installed)

645 mm (W) x 695 mm (D) x 833 mm (H) (25-25/64" (W) x 27-3/8" (D) x 32-51/64" (H)) (With the

document cover installed)

Weight

Approx. 95 k

(209.4 lbs.) (With the reversing single pass feeder installed)

Approx. 88 k

(194.0 lbs.) (With the document cover installed)

Overall dimensions

986

mm (W) x

695

mm (D) (

38-53/64

" (W) x

27-3/8

" (D)) (when bypass tray is extended)
