Installing the Printer Driver
120
2
Click the Windows Start button and then click Run.
3
Typ e Q:\Setup.exe (substitute the letter of your CD-ROM drive for “Q”) and
then click the OK button.
4
The “Readme First” window will appear. Read the text and then click Next.
5
Select User Tools and click Next.
6
Select “PCL XL Printer Driver” and click Next.
7
The name of the printer driver to be installed from the CD-ROM will appear.
Click Start.
8
When the Type of Model window appears, select your model and tray/casette
configuration.
9
Follow the instructions on the screen. When the following window appears,
click Browse and select “SHARPFO-DC500(600)” (or the name that was
entered for the printer when the printer driver was installed in the server).
10
Follow the instructions on the screen to complete the installation.
