Print Hold

Deactivating Print Hold

To deactivate Print Hold, follow the steps below.

♦ Print Hold cannot be deactivated while received faxes are held in memory.

(while [PRT. HOLD DATA EXIST] ) appears in the display). First print the

received faxes and then deactivate Print Hold.

1 Press , then press until [ACTIVATE PRINT HOLD] appears.

2 Press .

3 Press to select “NO”.

Display: [ENTER PASSCODE]

3 Enter the Print Hold code.

4 Press .

5 Press to exit.

PRINT HOLD

START

STOP
