4-7

CHAPTER4

ADDING TONER

Tap on the top of the toner cartridge to ensure that the

cartridge completely empties.

CAUTION

Be sure to perform this step. If not, some toner may be scattered

when the cartridge is removed.

Slide the empty toner cartridge back along the guides

and remove it.

●

The cartridge opening will be closed as it is moved back along

the guides.

Push the toner box back into the copier.

Close the front cover.

NOTE:

Add only one cartridge of the color toner indicated as being low or

empty.

SUPPLIES Adding toner
