Installing the Printer Driver
118
11
Click the Close button in the Printer Ports window.
12
Make sure the new port is selected in the list of ports and then click the Next
button.
13
The Add Printer Wizard will display a list of printer models and manufacturers.
Click the Have Disk button.
14
Insert the PRINTER UTILITIES CD-ROM into your CD-ROM drive. If the
“Readme First” window appears, click Cancel to close the window.
15
Enter the path Q:\Option\English\Nt_pclxl (substitute the letter of
your CD-ROM drive for “Q”) and click the OK button.
16
The printer driver name will appear in the Add Printer Wizard. Click Next.
