AL-2051 SIMULATION, TROUBLE CODES 10 - 9
22 21 Scanner counter display [Function]
The scanner counter is displayed.
[Operation]
22 RSPF JAM counter [Function]
The RSPF JAM counter is displayed.
[Operation]
24 01 JAM total counter clear [Function]
When [ENTER]/[START] key is pressed, the JAM total counter is cleared to 0 and "000,000" is
displayed on the LCD/display.
[Operation]
04 RSPF counter clear [Function]
When [ENTER]/[START] key is pressed, the RSPF counter value is cleared to 0 and "000,000"
is displayed on the LCD/display.
[Operation]
05 Duplex counter clear [Function]
When [ENTER]/[START] key is pressed, the duplex counter value is cleared to 0, and "000,000"
is displayed on the LCD/display.
[Operation]
07 Drum counter clear [Function]
When [ENTER]/[START] key is pressed, the drum counter value is cleared to 0, and "000,000"
is displayed on the LCD/display.
[Operation]
08 Copy counter clear [Function]
When [ENTER]/[START] key is pressed, the copy counter value is cleared to 0, and "000,000" is
displayed on the LCD/display.
[Operation]
09 Printer counter clear [Function]
When [ENTER]/[START] key is pressed, the printer counter value is cleared to 0, and "000,000"
is displayed on the LCD/display.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
1) Initial display
22-21 SCAN CNT
***,***
1) Initial display
22-22 S JAM CNT
***,***
1) Initial display
24-01 JAM TTL CLR.
CLEARED 000,000
1) Initial display
24-04 SPF CLR.
CLEARED 000,000
1) Initial display
24-05 DPLX CLR.
CLEARED 000,000
1) Initial display
24-07 DRUM CLR.
CLEARED 000,000
1) Initial display
24-08 COPIES CLR.
CLEARED 000,000
1) Initial display
24-09 PRT.CLR.
CLEARED 000,000
