GETTING STARTED

Operation

panel

PART NAMES AND FUNCTIONS

Part names and functions

q AUTO/MANUAL/PHOTO ( / / ) key

and indicators (p. 15)

Use to sequentially select the exposure modes: AUTO,

MANUAL ( ), or PHOTO ( ).

w Alarm indicators

: Paper required indicator (p.13)

: Misfeed indicator (p.28)

: TD cartridge replacement required indicator

(p.24)

: Drum replacement required indicator (p.26)

e Paper feed location/misfeed location indica-

tors (p. 28)

The selected paper feed location is shown by a lit

indicator ( ).

The misfeed location indicator ( ) blinks when a

misfeed has occurred.

r INTERRUPT key and indicator (p. 21)

Interrupts a copy run.

t Copy quantity display

Displays the specified copy quantity during the ready

condition and displays the copy countdown as copies

are made. Also see items !3 and !5.

y CLEAR ALL ( ) key

Clears all selected settings and returns the copier to the

initial settings.

u POWER SAVE ( ) indicator (p. 34)

Lights up when the copier is in the preheat mode.

i Light ( ) and dark ( ) keys and indicators

(p. 15)

Use to adjust the MANUAL ( ) or PHOTO ( )

exposure level.

o TRAY SELECT ( ) key (p. 15)

Use to manually select a paper tray.

!0 PRESET RATIO selector keys and indicators

(p. 17)

Use to sequentially select preset reduction/enlargement

copy ratios: 50%, 64%, 77%, 95%, 100%, 121%, 129%,

141%, 200%.

!1 ZOOM indicator (p.17)

Lights up when a zoom ratio is set.

GETTING STARTED
