A40509,R-8000G O/M

TINSEB012WRRZ- D31 Printed in Thailand

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, NJ 07430-2135

2003.9

SPECIFICATIONS

AC Line Voltage:

AC Power Required:

Output Power:

Microwave

Top Heater

Side Heater

Frequency:

Outside Dimensions:

Cavity Dimensions**:

Oven Capacity**:

Cooking Uniformity:

Weight:

Single phase 208V, 60Hz, AC only

1800W 9.0 amps. (Microwave)

2900W 14.0 amps. (Convection)

3250W 16.0 amps. (Speed Cooking)

1000W* (IEC Test Procedure)

1500W

1200W

2450 MHz

"(W) x 16

"(H) x 25

"(D)

"(W) x 8

"(H) x 13

"(D)

1.1 Cu.Ft.

Turntable system, 13" diameter

Approx. 87 lb

* The International Electrotechnical Commission’s standardized method for measuring output wattage. This

test method is widely recognized.

** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding

food is less.

In compliance with standards set by:

FCC – Federal Communications Commission Authorized.

DHHS – Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I,

Subchapter J.

– This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc.

- This symbol on the nameplate means the product is certified by NSF International (NSF-4).

R-8000G P.29- 03.9.24, 10:59 AM34
