Loveland Fire/Rescue

Pumper

Production Specification

SVI #769 Page 37 of 125 June 17, 2010

..\4) Pricing & Change Orders\Production Change Order.pdf

STEERING COLUMN/ WHEEL

The cab shall include a Douglas Autotech steering column shall be a seven (7) position tilt and 2.25 inch telescopic type

with an 18.00 inch steering wheel located on the left side of the cab designating the driver’s position. The steering wheel

shall be covered with black absorbite padding.

The steering column shall contain a horn button, self-canceling turn signal switch, four-way hazard switch and headlamp

dimmer switch.

POWER STEERING PUMP

The hydraulic power steering pump shall be a TRW PS and shall be gear driven from the engine. The pump shall be a

balanced, positive displacement, sliding vane type.

ELECTRONIC POWER STEERING FLUID LEVEL INDICATOR

The power steering fluid shall be monitored electronically and shall send a signal to activate an audible alarm and visual

warning in the instrument panel when fluid level falls below normal.

FRONT AXLE CRAMP ANGLE

The chassis shall have a front axle cramp angle of 48 degrees to the left and 44 degrees to the right.

POWER STEERING GEAR

The power steering gear shall be a TRW model TAS 65 with an assist cylinder.

CHASSIS ALIGNMENT

The chassis frame rails shall be measured to insure the length is correct and cross checked to make sure they run parallel

and are square to each other. The front and rear axles shall be laser aligned. The front tires and wheels shall be aligned

and toe-in set on the front tires by the chassis manufacturer.

The completed apparatus shall be rechecked for proper alignment once the chassis has been fully loaded and before

being placed in service.

REAR AXLE

The rear axle shall be a Meritor model RS-24-160 single drive axle. The axle shall include precision forged, single

reduction differential gearing, and shall have a rated capacity of 24,000 pounds.

The axle shall be built of superior construction and quality components to provide the rugged dependability needed to

stand up to the fire industry’s demands. The axle shall include rectangular shaped, hot-formed housing with a standard

wall thickness of 0.50 of an inch for extra strength and rigidity and a rigid differential case for high axle strength and

reduced maintenance.

The axle shall have heavy-duty Hypoid gearing for longer life, greater strength and quieter operation. Industry-standard

wheel ends for compatibility with both disc and drum brakes, and unitized oil seal technology to keep lubricant in and help

prevent contaminant damage will be used.
