Part Names

ENG 1-1

(Front)

See page 4-6.

See page 4-31.

(Side)

See pages 2-1, 4-4 and 4-31 for button operations.

(Rear)

*1 See the Setup Guide.

And see page 7-1 for external equipment connection.

See page 8-2 for details on the Audio Select function.

*3 For EQ10U, LE650U, C6500U and LE642U models:

Use HDMI IN 1 to connect ARC-compatible equipment.

For UQ17U, TQ15U, SQ17U, SQ15U, SQ10U and LE657U models:

Use HDMI IN 3 to connect ARC-compatible equipment.

*4 For UQ17U, TQ15U, SQ17U, SQ15U and SQ10U models:

Connect 4K signals (HDCP2.2) to the HDMI IN 1 terminal.

(4K60P is not supported.)

See page 7-6.

The illustrations and on-screen displays in this operation manual are for explanation purposes

and may vary slightly from the actual operations.

The examples used throughout this manual are based on the LC-60LE650U model.
