Specifications
Product specifications
Model name
LL-T19D1-H (Frosty gray)/LL-T19D1-B (Black)
LCD display
48 cm measured diagonally TFT LCD module
Resolution (max.)
SXGA 1280 x 1024 pixels
Displayable colors (max.)
Approx.16.77 million colors (8 bit )
Brightness (max.)
300 cd/m
2
Dot pitch
0.294(H) x 0.294(V) mm
Contrast ratio
700:1
Angle of visibility
Left-right 170°; Up-down 170°
(contrast ratio
>
=
10)
Screen display size
Horizontal 376.3 mm x Vertical 301.1 mm
Video signal
Analog: Analog RGB (0.7 Vp-p) [75Ω]
Digital: DVI standard based on 1.0
Sync signal
Separate Sync (TTL level: +/-), Sync on
Green, Composite Sync (TTL level: +/-)
Expansion compensation
Digital scaling (Enlarges VGA/SVGA/XGA etc. to
full screen size.)
Plug & Play
VESA DDC2B compatible
Power management
VESA: based on DPMS
DVI: based on DMPM
Input signal terminal
Analog:15 pin mini D-sub (3 rows) x 2
Digital: 24 pin DVI-D x 1
Screen tilt
Upward approx. 0 - 20°; downward approx. 0 - 5°
Screen swivel
Approx. 90° from left through right (Turn table type)
Power supply
AC100 - 240 V, 50/60 Hz
Temperature of operating environment
5 - 35°C
Power consumption
43 W maximum,
2.8 W when in power-saving mode
Dimensions
Approx. 423(W) x 222(D) x 392 - 439(H) mm
Weight
Approx. 6.9 kg (approx. 4.7 kg excluding stand)
(Excluding signal cable.)
Dimensions (Units: mm)
- Analog signal cable: approx. 1.8 m
- Digital signal cable, NL-C01E (purchased
separately): approx. 2.0 m
T19D1_gb.p65 2/14/2003, 3:07 PM23
