Sharp AR-203E X Instrukcja Użytkownika

StartOnline ManualAR-203E

INDEXCONTENTS82This feature allows you to print two or four document pages onto a single page.To use this function, open the printer driver setup scre

INDEXCONTENTS92When printing begins, the Print Status Window activates and appears on the screen.The Print Status Window is a program designed to show

INDEXCONTENTS103The flow chart shown below provides scanning overview.*1:TWAIN is an industry standard for interface of image data processing devices

INDEXCONTENTS113The SHARP scanner driver conforms to TWAIN, the industry standard, making it compatible with a variety of TWAIN-compliant applications

INDEXCONTENTS1234Select "Acquire Image" from the "File" menu, or click the "Acquire" button ( ).The scanner driver setup

INDEXCONTENTS133Scanner Driver SettingsThe scanner driver setup screen consists of the "Set-up screen", which lets you select scan settings,

INDEXCONTENTS143Preview screenPreview windowClick the "Preview" button in the Set-up screen to display the scanned image. You can specify th

INDEXCONTENTS153If you are using Windows XP/Vista, you can use the WIA driver to scan from Sharpdesk, Paint and other WIA-compliant applications. The

INDEXCONTENTS1633Select the paper source and picture type, and click the "Preview" button.The preview image will appear.If you placed the or

INDEXCONTENTS173The procedure for scanning with the "Scanner and Camera Wizard" in Windows XP/Vista is explained here. The "Scanner and

ContentsHow to Use the Online Manual 1Printing Overview 2Basic Printing 3Starting the Printer Driver Using the "Start" Button 4Printer Drive

INDEXCONTENTS1835Select the "Picture type" and "Paper source", and click the "Next" button.If you placed the original on

INDEXCONTENTS1937When scanning ends, the following screen will appear. Select the next task you wish to perform, and then click the "Next" b

INDEXCONTENTS203Button Manager is a utility software to link scanning functions to the SCAN key on the unit. This software enables you to set scanning

INDEXCONTENTS213After being installed, Button Manager normally keeps active under the Windows operating system. Follow the steps shown below to set sc

INDEXCONTENTS224When any trouble has occurred in the unit, first, verify whether you can make a copy or not with the unit. Check the items shown below

INDEXCONTENTS234CHECK 1 Is the interface cable compatible with the unit and computer?Interface cables compatible with this unit are USB cables.USB cab

INDEXCONTENTS244Reference: Plug and Play Screen does not Appear (when the USB is connected)CHECK 1 Is there enough computer memory or hard disk space?

INDEXCONTENTS254If the Plug and Play screen does not appear after you connect the unit to your computer with a USB cable and turn on the power of both

INDEXCONTENTS264If the MFP driver cannot be installed under Windows 2000/XP, check your computer's settings according to the following procedure.

INDEXCONTENTS274If print output is faint, uneven or smeared, follow the steps listed below.CHECK 1 Has the printer driver been specified to suit both

INDEXCONTENTS1This Online Manual provides instruction for the operation of your new unit. Please read the following explanation of how to use the Onli

INDEXCONTENTS284If a document is printed skewed or partly off the paper, follow the steps listed below.CHECK 1 Is the paper size loaded in the tray th

INDEXCONTENTS294If nothing prints even when the unit is turned on, please wait a few moments. The unit needs a longer time to process intricate data.

INDEXCONTENTS304If you get poor quality as a result of scanning a job, and you cannot improve the quality by changing preferences, refer to the check

INDEXCONTENTS314If the scanned image is incorrectly positioned, refer to the check list shown below.CHECK 1 Have you placed the original straight?Plac

INDEXCONTENTS324If you cannot scan the image, turn off your computer. Press the power switch on the unit to turn it off, unplug the unit from the powe

INDEXCONTENTS334If printing or scanning is not possible, or Button Manager does not function correctly, check the items in "Nothing Prints"

INDEXCONTENTS34534(continued)*1:Will be reduced to A4 size or the specified size before printing.*2:This initial setting may vary depending on your op

INDEXCONTENTS35535Tab Setting Selections Initial settingAdvancedPrint Quality Draft/Normal/Photo Normal2 Gradation Print On/Off Off[Image Adjustment]B

Index6A Application Selection 20"Auto Scan Area Adjustment" button14B Basic Printing 3Border 8Button Manager 20Button Manager Settings 21F F

AR203E_v1

INDEXCONTENTS22The flow chart shown below provides printing overview.Reference: For more information on printing, see Basic Printing.Cautionz The prin

INDEXCONTENTS32This is a printing example using WordPad to print a document onto A4 size paper.1Start WordPad, make a new file, and enter the text you

INDEXCONTENTS42You can open the printer driver and change the printer driver settings from the Windows "start" button. Settings adjusted in

INDEXCONTENTS52To view Help for a setting, click the ( ) button in the upper right-hand corner of the window and then click the setting.TabIndex which

INDEXCONTENTS62To print a watermark, for example "CONFIDENTIAL", on your document, refer to the following steps. Open the printer driver and

INDEXCONTENTS72This printer driver can adjust the zoom ratio for printing according to the paper loaded in the unit.Follow the steps shown below to us
