Installing Options in the Diskette Drive Compartment
7
Push the bezel from the bottom of the computer and
remove it.
8
Refer to the manual that came with the option to install it
and its bezel in the compartment.
9
Close the keyboard and reconnect all cables.
10
If the option in the diskette drive compartment requires
power, start the ThinkPad Features program and set the
parameter to send power to it.
OS/2
WIN
If you are using OS/2 or Windows,
1
Start the ThinkPad Features program.
2
Select Power; then select Diskette Drive Compartment
in the
Power for devices
menu.
DOS
If you are using DOS, use the PS2 command at the command
prompt.
PS2 command:
Page 41.
152 IBM ThinkPad 755CX User's Guide
