Spare part
number
Description
647603-001 Heat sink for use in computers with UMA graphics
647604-001 Heat sink for use in computers with discrete graphics
647677-001 Display hinges for use in HP ProBook 6560b models (includes left and right hinges, brackets, and covers)
649651-001 128-GB solid-state drive (SSD)
649652-001 160-GB solid-state drive (SSD)
649653-001 DVD-ROM drive for use in HP ProBook 6560b models
649654-001 DVD±RW and CD-RW SuperMulti DL combo drive for use in HP ProBook 6560b models
649655-001 Blu-ray ROM DVD±RW SuperMulti DL Drive for use in HP ProBook 6560b models
651041-001 DVD-ROM drive for use in HP EliteBook 8560p models
651042-001 DVD±RW and CD-RW SuperMulti DL combo drive for use in HP EliteBook 8560p models
651043-001 Blu-ray ROM DVD±RW SuperMulti DL Drive for use in HP EliteBook 8560p models
651044-001 Blu-ray BD-R/RE DVD±RW SuperMulti DL Drive for use in HP EliteBook 8560p models
652688-001 Hard drive cradle
653784-001 System board for use in HP ProBook 6560b computers with UMA graphics, HM65 boards, and WWAN (use
in Russia and the People's Republic of China)
653785-001 System board for use in HP ProBook 6560b computers with discrete graphics, HM65 boards, and WWAN
(use in Russia and the People's Republic of China)
653786-001 System board for use in HP ProBook 6560b computers with UMA graphics, QM67 boards, and WWAN (use
in Russia and the People's Republic of China)
653787-001 System board for use in HP ProBook 6560b computers with discrete graphics, QM67 boards, and WWAN
(use in all countries and regions except for Russia and the People's Republic of China)
653788-001 System board for use in HP EliteBook 8560p computers with UMA graphics (use in Russia and the
People's Republic of China)
653789-001 System board for use in HP EliteBook 8560p computers with discrete graphics (use in Russia and the
People's Republic of China)
654129-001 System board for use in HP ProBook 6560b computers with UMA graphics, HM65 boards, and no WWAN
(use in all countries and regions except for Russia and the People's Republic of China)
654305-001 System board for use in HP ProBook 6560b computers with UMA graphics, HM65 boards, and no WWAN
(use in Russia and the People's Republic of China)
657829-001 Display Panel Support Kit for use in HP ProBook 8560p models
657831-001 Display Panel Support Kit for use in HP ProBook 6560b models
50 Chapter 3 Illustrated parts catalog
