Introduction
About the Indicators on the Projector
Attaching and Removing the Lens Shipping Block
When attaching the lens shipping block, be sure to return the lens shift
lever to the centre position. If the lens is shifted upwards or downwards,
the lens shipping block cannot be attached.
Power indicator
Temperature
warning
indicator
Lamp indicator
Temperature
warning indicator
Lamp indicator
Power indicator
Maintenance indicators
Power indicator
Lamp indicator
Temperature
warning indicator
Status of the lamp
Green on/Red on
...
Normal
Red blinks
...
Abnormal
Green on
...
Normal
Green blinks
...
The lamp is warming up.
Red on ... Change the lamp.
Off
...
Normal
Red on
...
The internal temperature is
abnormally high.
Page
52
52
52
XV_Z10E_E_p08_15.p65 03.11.7, 4:14 PM11
