Basic Operation
-47
Supplied
accessory
USB cable
USB port
Notebook computer
USB cable
Using the Wireless Presentation Function of the GyroRemote
The remote control can perform mouse operations on a computer screen displayed on the
actual screen. The remote control can also be used as a pointer. (See page 44)
Connecting the
Computer and the Projector
1 Connect the projector to the
computer using the supplied
USB cable.
Note
• This function only works with
Microsoft Windows OS and Mac OS.
However, this function does not
work with the following operating
systems that do not support USB.
• Versions earlier than Windows 95.
• Versions earlier than Windows NT
4.0.
• Versions earlier than Mac OS 8.5.
PG-M25X#E#p33_49.p65 02.4.29, 3:13 PM47
