COPY FUNCTIONS
SELECTING THE VERTICAL AND HORIZONTAL
COPY RATIOS SEPARATELY
(XY ZOOM copying)
The XY ZOOM feature allows the horizontal and vertical copy ratios to be changed independently.
Example:
Reduction only in the horizontal direction.
Ratios that can be selected will vary depending on the position of the original.
1
Place the original(s) in the document
feeder tray or on the document glass.
2
If the original is placed on the
document glass, select the original
size. (p.18)
3
Press the [XY-ZOOM] key.
XY-ZOOM Indicator
lights up.
The current value for the
vertical direction will
appear in the display.
4
Use the [PRESET RATIO] selector
keys ( , ) and [Zoom] keys ( , )
to change the copy ratio in the vertical
direction.
Press the [PRESET
RATIO] selector keys
( , ) to select a ratio
close to the desired ratio,
and then press the
[Zoom] keys ( , ) to
adjust the ratio in
increments of 1%.
The ratio appears in the
display.
5
Press the [Copy ratio display] key
().
The selected ratio for the
vertical direction will be
entered.
• To use the XY ZOOM feature with the DUAL PAGE COPY feature, set the DUAL PAGE COPY feature first and
then the XY ZOOM feature.
• The XY ZOOM feature cannot be used in combination with the AUTO IMAGE function.
Original position Selectable ratios
Document glass 25% – 400%
SPF 50% – 200%
Original Copy
Note
XY-
ZOOM
PRESET RATIO
25 400%
ZOOM
AR-5316-5320-EX.book 24 ページ 2005年4月8日 金曜日 午前9時35分
