20
MAKING COPIES
BYPASS FEED (special paper)
The bypass tray is used to copy onto transparency film, labels, and other
special purpose papers. Up to 100 sheets of standard copy paper can be set
in the bypass tray.
1
Unfold the bypass tray.
●
When feeding 8-1/2" x 14" or 11" x 17" sized paper, extend the feeder
tray.
2
Set the paper guides to the copy paper width.
3
Insert the copy paper (print face down) all the way into
the bypass tray.
●
Up to 100 sheets of standard copy paper measuring from 5-1/2" x
8-1/2" to 11" x 17" can be loaded in the bypass tray.
●
Transparency film, labels, and other special purpose papers (except
envelopes) must be fed individually.
Up to 10 envelopes can be set.
●
When adding paper, first remove remaining paper, combine it with the
paper to be added and then reload as a single stack.
●
When loading envelopes, make sure that they are straight and flat.
Bypass feed (special paper)
For special purpose papers, the original image must be
smaller than the paper or media for copying.
If the original image is bigger than the paper or media, this
may cause smudges on the edges of the copies.
Also for standard copy paper, smudges may appear if the
copy paper is not at least as large as the original image.
