Built-in With optional AR-EB9

CPM

First copy time

1st.

7.2

sec.

.....

Scan Once/Print Many and

Electronic Sorting

Document is

scanned...

Multi-page

original

stored in

memory...

Copies

electronically sorted...

and stacked offset

during output.

1,100

Rotation Copy

Edge Erase

2-in-1/4-in-1 Copy Margin ShiftXY Zoom

Centre EraseDual Page Copy Mode*

Original

Analogue

Digital

Card Shot

Back

Front

Back

Front

CARD

Need a simple solution for keeping up with today’s fast-paced and graphic-intensive business communications? The AR-M161

has all your everyday office needs covered in one efficient document solution that delivers outstanding copying and printing,

and brilliant colour scanning. In addition to its wide range of superb functions, the AR-M161 offers a world of performance-

boosting options for you to choose from: Super G3 faxing, powerful network scanning and printing, advanced copy/print

functions, and more. Since you can choose the system configuration best suited to your office needs, the AR-M161 brings you

everything you need — with the flexibility to grow. Conveniently packaged in a compact and user-friendly design, the

AR-M161 delivers the versatility and ease-of-use that today’s businesses are looking for.

• Productive Copying

• Quick copy speed of max. 16 cpm

• Scan Once/Print Many function and optional electronic

sorting

• Optional 40-sheet SPF (single pass feeder)

• Max. 1,100-sheet paper capacity

• Added functions with optional Dual Function Board

• Colour Scanning

• Full-colour scanning at 600 dpi and up to A3 in size

• Sharpdesk™ provides easy desktop management of

documents in over 200 file types

• Button Manager for quick and easy scanning

• Upgradeable to network colour scanning (scan to e-

mail/desktop/FTP server)

• LDAP compatibility for easy browsing of e-mail addresses

• Speedy Faxing

(option)

• Super G3 faxing and JBIG

compression

• Quick on-line transmission

• Max. 300 speed dials

• User- and Environment-Friendly

• Universal design concept and

5-line LCD operation panel

• Energy-efficient design

• Lead-free wiring harnesses and AC

power cords

• Chromium-free surface-treated steel

sheet

• Performance Printing

• Standard printing at 12 ppm, upgradeable to 16 ppm

• RIP Once/Print Many function for productive printing (option)

• Speed-enhanced Sharp Printer Language with Compression (option)

• Smart sharing with three PCs via IEEE 1284, USB 1.1, and optional

USB 2.0

• Upgradeable to network printing with network utilities

• IP/MAC address filtering prevents unauthorised access (option)

One compact solution answers

your individual office needs

One compact solution answers

your individual office needs

Speedy Copying and Quick First Copy Time

The AR-M161 has a quick first copy time

of 7.2 seconds* to save valuable time

when performing multiple short-run

jobs. And with a continuous copy rate of

16 cpm (A4 size [8

/2" x 11"]), you can

do more copy jobs in less time.

*Depends on the operating environment and the status of use.

Scan Once/Print Many and Optional

Electronic Sorting

The AR-M161’s Scan

Once/Print Many (SOPM)

function does one scan of

multiple-page documents

and stores them in memory

for making up to 999 copies

of each page. The optional

AR-EB9 Dual Function Board

increases efficiency with an

Electronic Sorting function,

which automatically

collates multiple sets of

copies in page order without

the aid of a sorter. The

AR-M161 also stacks each

set slightly shifted apart from the previous (offset stacking) for

easy retrieval. All this adds up to speedy copying that boosts

productivity even for large-volume documents.

Time-Saving SPF

(option)

For copying productivity, the AR-M161 can be equipped with the

optional AR-SP6

N SPF (single pass feeder). It eliminates the

tedious task of placing

pages by hand and allows

you to automatically make

copies from a stack of up to

40 originals.

Paper Capacity

The AR-M161 comes

standard with a 250-

sheet paper tray and a 100-

sheet multi-bypass feeder. Two

types of extra paper drawers

are available for a total paper

capacity of up to 1,100 sheets.

Versatile Editing Functions

The AR-M161 is standard equipped with Dual Page Copy Mode

and XY Zoom. Additional image editing functions are available

with the optional AR-EB9 upgrade that make copying even more

convenient.

*Not available when using SPF.

Card Shot

(option)

This function enables one-touch

scanning and copying of both

sides of a card (credit cards, ID

cards, etc.) onto a single page.

Note: Not available when using SPF.

Superb Image Quality

600 dpi resolution and 256-level greyscale ensure finely detailed

reproduction, while Digital Auto Exposure Control provides

optimum copy contrast. For the best results, users can select Text

mode for text-only originals or Photo mode that gives detailed,

high-quality reproduction of photos and delicate halftone images.

Other Key Features

• Wide zoom range from 25% to 400% with 10 preset ratios

• Automatic paper/magnification selection

• Copy/print/scan auditing (50 accounts total)

• Cost-efficient Toner Save mode

COPYING
