TROUBLESHOOTING

The display turns off.

Any other indicators turned off.

→ If other indicators are lit, the machine is in "Preheat mode". Press

any key on the operation panel to resume normal operation.

START indicator blinks.

→ The machine is in auto power shut-off mode. Press the [START]

key ( ) to resume normal operation.

Lighting fixture flickers.

The same power outlet being used is for the lighting

fixture and the machine.

→ Connect the machine to a power outlet which is not used for other

electric appliances.

–

Problem Cause and solution Page
