Using MANUAL Reception Mode

1 When the fax machine rings, answer

the call on an extension phone

connected to the same line.

2 If you hear a fax tone, press on the fax machine.

• If the other party first speaks with you, press after speaking. (Press

your START key before the sender presses their Start key.)

• If there is a document in the feeder, remove the document before pressing

(otherwise the document will be transmitted).

3 When RECEIVING appears in the

display, hang up.

START/

ENTER

START/

ENTER

START/

ENTER

Using MANUAL Reception Mode
