Clearing Paper Jams
131
9. Trouble-
shooting
5
Replace the drum cartridge.
• Make sure the drum cartridge is
inserted in as far as it will go.
6
Replace the toner cartridge and then
close the print compartment cover.
7
If you have a paper cassette and the
display still indicates that paper is
jammed, pull out the cassette and
remove the jammed paper.
8
Replace the paper cassette.
OR
GREEN
BLUE
GREEN
BLUE
