Operation References

Lithium battery cover (p. 12)

Tripod socket*

Card slot cover (p. 11)

Left view

Dioptre adjustment dial (p. 18)

Battery release (pp. 7, 12)

* When attaching a tripod

with a guide pin, do not

attach the pin to the bottom

of the camcorder.

LCD monitor

(p. 19)

Earphones jack

(VL-Z5 only) (p. 29)

DV terminal (pp. 66, 68)

USB terminal (p. 83)

DC IN jack (pp. 8, 9)

AV terminal

(pp. 30, 63, 64, 68)

Terminal cover

(pp. 29, 30, 63, 64, 66, 68, 83)
